Zhongtuo High-Speed Roofing Sheet Machine Technical Report

I. System Overview

Cangzhou Zhongtuo's advanced roof sheet roll forming machine represents the cutting edge in automated building material manufacturing. High speed roof tile making machine with high speed hydraulic decoiler and automatic stacker can achieve a high degree of automation.

II. Core Technical Specifications

1. Production Capacity

• Maximum speed: 25 meters/minute (1680㎡/hour)

• Tile dimensions: 1000-3000mm length x 300-500mm width

• Thickness range: 0.3-1.2mm (adjustable in 0.05mm increments)

1. Material Compatibility

• Substrates: Galvalume steel, aluminum-zinc alloy, copper, Stainless steel

• Backings: PE foam, fiberglass mat, soundproofing layers

III. Key Technological Innovations

1. Smart Manufacturing System

• Siemens PLC controls entire production flow

• ABB robotic arms for automated material handling

IV. Performance Advantages

1. Precision Engineering

• Hydraulic press with 250-ton force (±1% accuracy)

• CNC punching achieves 0.02mm positional tolerance

• Automatic thickness control via laser measurement

1. Durability Enhancements

• Tungsten carbide coated rollers (50,000+ hour lifespan)

• Dust-proof servo motors (IP67 rating)

• Corrosion-resistant frame (SUS304 stainless steel)

1. Operational Benefits

• 98% uptime guarantee with predictive maintenance

• 30% faster setup than conventional machines

• 15% lower energy consumption per unit

Zhongtuo has 11 years experience in exporting roll forming machine,

Trust Zhongtuo, trust Best quailty and Comprehensive service
More details contact Daniel
